Pallet Stacker

Short Description:

★ Mechanical + electrical positioning method, precise positioning;
★ With automatic and manual dual operation mode;
★ Meet the beat, any loop;
★ Imported brand high-speed elevator with higher efficiency;
★ Anti-falling device and pallet entering and leaving the chamber without jitter;
★ The lifting adopts hoisting type with safety protection design;

Product Detail

Product Tags

★Equipment function

    The stacker sends the polished or roughened PC components and their pallet from the roller conveyor line to the designated location of the curing chamber;and the cured PC components and their pallet are taken out of the curing  and transported to the roller conveyor line.The stacker control system has two control modes, manual and automatic. The automatic mode can set the action cycle arbitrarily,and the site can be unattended.

★Equipment composition

    Standard item:

  1.Walking system
  3.Lifting system
  4.Pallet conveyor system
  5.Jack/pull pallet mechanism
  6.Vertical positioning mechanism
  7.Horizontal positioning mechanism
  8.Door lift mechanism
  9.Control System
  10.Hydraulic system
  11.Controlling software
  12.Guardrail, cage ladder

    Optional item:

  1.Simulated monitor system
  2.Video monitor system
  3.Walking track
★Equipment feature

   (1) It can automatically identify the pallet and storage position, automatically access the pallet, and automatically open and close the chamber door;

   (2) Electrical + mechanical dual positioning system, high positioning accuracy;

   (3) The horizontal running and the lifting of the mold table are synchronized to improve the operation efficiency;

   (4) Multiple safety measures are set for the lifting system and the taking/feeding mechanism, so that the operation is stable, safe and reliable;

   (5) Configure sound and light alarm device;


★Company Introduction

    Hebei Xindadi electromechanical Manufacturing Co., Ltd. is a world leading technology enterprise of precast concrete processing equipment, and is committed to becoming a competitive enterprise of intelligent concrete processing equipment.The company now has four manufacturing bases in Zhengding, Xingtang, Gaoyi, and Yulin.We wholeheartedly provide customers with technical consultation and special design services for the factory production projects of precast concrete components, and system solutions for the whole life cycle of R & D, manufacturing, installation, commissioning and maintenance of complete sets of equipment, so as to meet the diverse needs of customers and create value for customers in all aspects.

System Introduction

    The production system for precast concrete elements has circulation production system,prestressed production system,stationary production system,flexible production system and nomadic production system.

Molds Introduction

      The molds are divided into prefabricated building molds, municipal road and bridge molds, wind power tower molds, high-speed railway molds, mold tables, prefabricated components supporting projects and hangers.
